sfp-560a研磨机

sfp-560a

dpc “dynamic pressure control”模式 (patent pending) 使用气动平行加压方式研磨光纤产品，例如： fiber arrays, mt和heavy cables,ipc mode 独立加压模式: 使用以往四角加压原理研磨光纤产品.

特点 / 优势

设计
开放的空间: 获得研磨夹具上方所有的空间
适合自动化生产线运用
传承sfp-550系列的简单

研磨方式
dpc “dynamic pressure control”模式 (patent pending) 使用气动平行加压方式研磨光纤产品，例如： fiber arrays, mt和heavy cables
ipc mode 独立加压模式: 使用以往四角加压原理研磨光纤产品.

其他特点
可编程(可记忆多大60种研磨工艺)
支持usb数据传输
支持现有所有550系列夹具
通用电源

sfp-560a 规格参数

weight:	22kg
dimensions:	w240w x d370 x h300 (mm)
polishing method:	rotation & revolution
pressure control	2n to 200n when polishing in dpc mode
power:	100-240 vac, 50/60h
required air	0.6mpa to 0.8mpa
motor speed:	revolution 70 to 200rpm rotation 1/100 of rev. speed.
film size:	5” (127mm)

支持研磨夹具及配件

i.p.c. holders
description:	platinum holder part #
fc/pc	ph55-fp-20 or 24
fc/apc	ph55-fp8*-18-i or 24
sc/pc	ph55-cp-20, 24 or 32
sc/apc	ph55-cp8*-18-i or 24 or 32
st/pc	ph55-sp-20 or 28
lc/pc	ph55-pl-24 , 40 or 48
lc/pc high pressure	ph55-pl-24hp, 40hp or 48hp
lc/apc	ph55-pl8a-20-b, 40 or 48
lc/apc high pressure	ph55-pl8a-20hp-b ph55-pl8a-40hp or 48hp
lc/pc duplex	ph55-pl-32dhp or 48dhp
lc/apc duplex	ph55-pl8a-32dhp-por
mu/pc	ph55-pm-24 or 40
mu/apc	ph55-pm8a-20
2.5mm ferrule	ph55-ff-20 or 40
1.25mm ferrule	ph55-flm-16, 24, 40 or 48
please contact for connector types not listed. 可根据客户要求定制研磨夹具必须指定ferrule的apc的角度类型（台阶或大锥）根据需要提供ipc研磨的各种固线器装置
mt holders & accessories
description:	mt holder part #
mt/pc holder	ph55-mt-24s1
mt/pc holder	ph55-mt-12s1
mt/apc holder	ph55-mt8a-24s1
mt/pc one-lever holder	ph55-mt-24sq1 new
mt/pc re-polishing holder	ph55-mt-12r1 new
mt/pc mega-axis holder	ph55-mt-36s1 new
washing station	mt-p-wsh-b
cable management	prm-p-cmh-b
torque wrench	n3ltdk-mt
cleaning brush	mt-p-brs-b

支持研磨耗材

polishing films for zr polishng
description:	film part #
30um silicon carbide	ga5d
9um diamond	dr5d-9u
3um diamond	dh5d-3u
1um diamond	dj5d-1u
silica	xf5d
*other types of films and liquid are also available up on request
polishing films for mt polishng
description:	film part #
adhesive removal & leveling	gc5d
rough polishing	ar5d
fiber protrusion	gh5d
finishing	fm5d-soap
*consumables for slurry polishing are also available upon request
rubber & glass pads available for various hardness & thickness (ask for details): 60, 65, 70, 75, 80, 85 & 90 durometer 4.8, 4.9, 5.0, & 5.05 mm thickness all for 5” diameter for mt polishing, pg5x-490-sr2, tacky glass pad is available, which psa backing is no longer needed.
